MMX WashBeam™

Discontinued
MMX WashBeam™ | ROBE lighting

MMX WashBeam™

Discontinued

Encompassing all the new technologies develeoped for the MMX Spot, the WashBeam provides the lighting designer with a huge range of features and effects in a single fixture.

Read More...

The Phillips Platinum 35 light source together with the Robe MMX optical system, produces a light output exceeding most traditional 1200 W products. Robin MMX WashBeam uses innovative internal motorized barndoors module for creating different unique shapes and chases, in the which also simulates barndoor effects. The module consists of four individually controllable blades and is rotatable by 180 degrees. With the change of a lens, the WashBeam switches from a super-flat, even wash - extendable out to 54 degrees into a tight 3 degree Beam effect machine - both options retaining all the key performance features of the MMX family - including full CMY colour mixing, saturated colour wheel, variable CTO, variable Hot-Spot control, motorised Zoom & Focus and Rotating indexable glass gobos - all adding up to a real advantage over other existing Beam products.

Light source

Philips MSR Platinum 35

Light output

beam mode : 235.000 lux @ 5m, wash mode : 86.700 lux @ 5m / 22.800 lm

Zoom range

Beam application: 3°-65°, Wash application: 4°-54°

Effects

rotating gobo wheel, internal barndoor module,

Innovations
GDTF – General Device Type Format
GDTF – General Device Type Format

The General Device Type Format creates a unified definition for exchange of data for the operation of intelligent luminaries, such as moving lights. The file format is human readable and developed using open source formats.

Product Video

Technical Specification

Source

Lamp: Compact high-pressure metal halide lamp

Base: PGJX36

Approved model: Philips MSR Platinum 35, 1200 W equivalent

Control: Automatic and remote on/off

Ballast: Electronic

Optical system
Electromechanical effects
Control and programming
Rotating gobos
Internal barndoors
Thermal specification
Electrical specification and connections
Approvals
Mechanical specification
Rigging
